SPC-5600

• 8 Core 9th/8th Gen Intel® Core™ i7/i5/i3 Processor (Coffee Lake) running with Intel® H310 Chipset
• DDR4 2666MHz memory, up to 64GB
• Fanless -25°C to 60°C Operating Temperature, optional supports operation with fan
• 2 DisplayPort and 1 DVI display interfaces support dual independent displays, up to 4K resolution
• 4 USB 3.1, 4 COM RS-232/422/485
• 4 Independent Intel® GigE LAN, iAMT 12.0 supported
• Supports WiFi/4G/3G/LTE/GPRS/UMTS
• 2 Mini PCIe sockets for PCIe/USB/SIM Card/mSATA expansions
• 12V DC Power Input

Feature higlights

• 8th gen Intel Core i7/i5/i3 processor (Coffee Lake) + Intel H310 chipset
• 6 cores computing
• 2 SO-DIMM sockets, up to 64GB DDR4 memory
• High-speed data transfer : PCIe 3.0 (8GT/s), SATA III (6G), USB 3.1 (5G), GigE LAN (1G)
• More than 10% system performance enhanced than Intel Kaby Lake platform
