AIE-KO22/32| AIE-KN32/42

The NVIDIA Jetson Orin NX module offers up to 100 TOPS, 3 times more than the NVIDIA Jetson AGX Xavier™ module, and approximately 5 times the NVIDIA Jetson Xavier™ NX module; NVIDIA Jetson Orin Nano module offers up to 40 TOPS, 80 times the NVIDIA Jetson Nano module. In other words, NVIDIA Jetson Orin NX and Orin Nano module set new standard for mainstream and entry-level edge AI in the smallest Jetson form factor.

AIE-KO22/32 and AIE-KN32/42 are edge systems with high expansion ability, built in 1x M.2 B-Key for LTE/5G, 1x M.2 E-Key for Wifi/BT and 1x M.2 M-Key for storage. To avoid insufficient data storage for edge computing, AIE-KO22/32 and AIE-KN32/42 support external M.2 2242 NVMe with fast data transmission.

To meet various embedded applications, especially challenging environments in smart factory, smart city, and smart transportation, AIE-KO22/32 and AIE-KN32/42 support operating temperature ranging from -25°C to 70°C and wide input power from 12 to 24VDC.

A product by Aetina
