AIE-PN33/43-2PSE | AIE-PN33/43-4PSE

Spotting as reliable and powerful AI inference device, the Aetina fanless and versatile expansion edge AI system – AIE-PN33/43-4PSE is designed to incorporate 4 x PSE PoE ports for PoE cameras connectivity, coupled with versatile I/O and expansion options to enable seamless deployment across multiple vertical markets. Leveraging the full power of NVIDIA® Jetson Orin™ NX, the AIE-PN33/43-4PSE drives up to 100 TOPS of AI performance, offering users full bandwidth and power package to complement and scale video inputs for AI inference on the edge.

AIE-PN33/43-4PSE drives for exceptional AI performance by integrating with the power of NVIDIA Jetson Orin NX module. It boasts up to 100 TOPS of AI performance, offering 5 times performance upgrade than Jetson Xavier™ NX module. Thanks to the 1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores, AIE-PN33/43-4PSE propels a new standard for mainstream edge AI devices.

AIE-PN33/43-4PSE is the fanless system with high expansion ability, built-in 1x M.2 B-Key for LTE/5G, 1x M.2 E-Key for Wifi/BT and 1x M.2 M-Key for NVMe expansion storage with fast data transmission. Its on-board 4 x PSE ports, each port supports IEEE 802.3af compliance and can supply up to 15W to PoE camera.

AIE-PN33/43-4PSE brings AI-based visual analytics to the edge. It powers up to 4 PoE cameras over four PSE ports while eliminating cabling. Its fanless design with -25°C to 55°C temperature range and 12-24V DC input enables reliable, maintenance-free operation. In the end, that makes AIE-PN33/43-4PSE perfect for AI-driven visual detection, recognition, and tracking at the challenge edge – from traffic roadside monitoring and smart cities to factories, farms, and construction sites

Aetina’s AIE-PN33/43-4PSE simplifies fleet management for edge AI systems with built-in support for EdgeEye remote monitoring and control. IT staff can use the EdgeEye cloud platform to monitor, control, and reboot distributed edge systems conveniently from a central location.

A product by Aetina
